SLXD5+ Receiver, Portable
SLXD5+ is a 'rugged' metal constructed, single-channel portable wireless receiver that provides 24-bit digital audio clarity, AES-256 encryption, efficient long-range UHF transmission and easy-to-use setup features. SLXD5+ has been designed for use on top of a camera or in an audio bag. The user is able to scan and deploy frequencies to a compatible SLX-D+ wireless transmitter with IR sync, or coordinate and monitor large channel configurations with many sources using Multi-Mic Mode. A bright OLED screen displays battery life in hours and minutes when used with the optional SB903 rechargeable Lithium-Ion battery. With a regional dependant tuning band 138MHz, and 32 available channels per frequency band, SLXD5+ can operate up to 11 compatible systems per 6MHz TV band; or 14 systems per 8MHz band. Dual 3.5mm jack outputs including a headphone monitor out and switchable line/mic output allow the user to connect to camera, recorder, or mixing device.
Spurious rejection: Greater than 75dB, typical. RF impedance: 50ohms. Frequency range: 20Hz - 20kHz, +1/-3dB. Audio impedance: 450ohm, balanced mono line; 240ohm, balanced mono mic; 400ohm, dual mono line; 200ohm, dual mono mic. Dimensions (W x D x H): 68 x 25.3 x 107mm. Weight: 182g
SLXD4+ Receiver, Single channel
One of four receivers in the SLX-D+ range, SLXD4+ is a desktop, single channel receiver that can be mounted in a 1U, 19-inch format by using the included mounting bracket kit. SLXD4D+ dual channel half-rack receiver unlocks hands-free oversight and management for seasoned volunteers and pro engineers alike, that delivers wireless excellence, wherever required. Wide-tuning SLXD+ transmitters and receivers stay in sync courtesy of a dedicated ShowLink Ease control link. Manage interference, scan for new channels and update for clear transmission automatically. Also monitor and configure via a paired mobile device. Each SLX-D+ component and system ships with AES-256 Encryption installed, for complete and secure peace of mind
The front facing panel of the SLXD4 receiver has all status identifying tools including a flashing/solid LED for sync status, and visual display showing both receiver and linked transmitter settings along with menus for adjustment. Power button, control knob, sync and exit buttons are also located on the front facing panel, along with an infrared port for syncing with selected transmitter.
The rear facing panel of the receiver houses all audio and data connectivity including BNC connectors for antenna A and B, DC power supply input, Ethernet port with associated LED for status, and audio outputs on both balanced 3-pin XLR and balanced 6.35mm jack. Rack mounting fixing is provided to fit 19-inch racking.
Audio frequency response: 20-20kHz. Audio output: balanced 3-pin XLR, 150ohm mic, 400ohm balanced line, 200ohm unbalanced line; balanced 6.35mm jack, 1.3kohm balanced, 670ohm unbalanced. Networking: single port Ethernet 10/100Mbps. Network addressing: DHCP or manual IP address. Power source: 15V DC, 360mA, tip positive. Dimensions (H x W x D): 42 x 197 x 152mm. Weight: 900g, without antenna.
SLXD4D+ Receiver, Dual-channel
SLXD4D has all the functionality and specifications as the SLXD4 receiver, however it is doubled in terms of channels.
Dimensions (H x W x D): 42 x 197 x 152mm. Weight: 930g.
SLXD4Q+ Receiver, Quad-channel
SLXD4Q+ has the functionality of the SLXD4+ receiver, however it is quadrupled in terms of channel count. The receiver operates over 138MHz wideband range, or 44MHz when used with narrowband transmitters.
Dimensions (H x W x D): 42 x 393 x 152mm. Weight: 1750g.
SLXD4QDAN+ Receiver, Quad-channel, Dante
SLXD4QDAN+ has all the functionality and specifications as the SLXD4Q+ receiver, however it incorporates Dante primary and secondary audio connections for redundancy. The Dante receiver carries Dante digital audio and control signals for audio distribution, monitoring, and recording, along with enabling remote device control via Shure Wireless Workbench software.
Dimensions (H x W x D): 42 x 393 x 152mm. Weight: 1750g.
