This range of K&M adjustable mic-arms have been designed to increase ergonomics within a studio or workstation set up.
258 - Table mounting mic arm
Table microphone arm - Fixes onto both flat surfaces and tubes, with a clamping range up to 53mm. A two-piece, telescopic, boom-arm, with an extension range of 560-1020mm, can be angled through 360 degrees and locked in place by a large, knurled, knob. The extendable boom is adjusted in length by a knurled-head screw and topped with a 3/8 inch thread for the connection of microphone clips. Weight 0.76kg. Black finish.
23840 - 0.8kg capacity
This desk arm, manufactured from steel, has multiple truss arms for stability when holding up to 0.8kg in weight. The arm has an extension of 460 to 960mm and a clamping range of 20-51mm, however the optional 23855 can be utilised where desk fixture is required to be midway across desk, as opposed to edge mounted. The threaded connector can be used as 3/8-inch or 5/8-inch. Four cable clips are provided however there is no integral cable included. Weight: 1.38kg
23850 - 0.8kg capacity, integrated wiring
A popular choice of desk arm manufactured from steel with multiple truss arms for stability whilst holding up to 0.8kg in weight. The arm has an extension of 460 to 960mm and has an integral microphone cable terminated with 3-pin XLR that extends 5m. The included desk clamp has a clamping range of up to 48mm, however the optional 23855 table flange can be used as an alternative. The threaded connector can be used as 3/8-inch or 5/8-inch. 23855 can be utilised where desk fixture is required to be midway across desk, as opposed to edge mounted. Weight: 1.72kg
23860 - 1.5kg capacity, integrated wiring
A single truss microphone desk arm with cable-through as standard. The integrated cable is 6m in length and terminates in 3-pin XLR connectors. Manufactured from a mix of aluminium and steel, 23860 can be used with the standard desk clamp, which has a clamping range of 0-48mm, or the option 23855 table mounting flange. The arm is capable of holding microphones up to 1.5kg in weight, and is adjustable from 460 to 960mm in length. 23855 can be utilised where desk fixture is required to be midway across desk, as opposed to edge mounted. Weight: 1.3kg
23865 - 1.5kg capacity
This microphone arm has the same feature set and physical specifications as 23860, however it doesn't have the cable through. Weight: 1.2kg.
23868 - 1kg capacity, integrated wiring
23868 is a slim microphone arm has a threaded connection in 3/8-inch or 5/8-inch, and is equipped with a table clamp that enables 'fast and flexible' deployment in studios or multimedia work environments. The integrated cable management allows the cables to be stowed in the cable channel to save space and remain hidden. Compatible with microphones weighing up to 1kg. The clamp covers a clamping range of 3 to 50mm. The scope of delivery also includes a table flange that enables stationary mounting. Weight: 1.3kg
23855 Table Flange
Manufactured from steel, 23855 is a table flange compatible with 23850 and 23860 desk arms. The mount has a base diameter of 73mm, and has three 5.2mm bore holes for fixing to a table surface via screws. Weight: 0.24kg
23856 Wall Mount
A 'robust and sturdy' wall mount for 23840/23850/23860/23865 microphone arm. The fitting allows a swivel range of up to 180-degrees. Mounting material included. Dimensions (WxHxD): 100 x 100 x 62mm. Weight: 0.23kg
